EC11 24P Encoder Switch

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button
Rotary Encoder Switch USED A variety of DVD players, CD portable audio, video monitors and other audio equipment control; Audio mixers, electronic instruments, etc. control; car navigation, car audio
  • EC11 Encoder Switch

  • LEGTOP

Availability:
Quantity:

Rotary Encoder Datasheet.pdf


Usage:

  1. A variety of DVD players, CD portable audio, video monitors and other audio equipment control;

  2. Audio mixers, electronic instruments, etc. control; car navigation, car audio Potentiometer

  3. Regulation and menu choices, a variety of common household appliances governor


Mechanical characteristics

Total rotational angle

360°

Click torque

20-100gf.cm

No. Of click

30 click step angle:12±2°

Bushing-nut tightening torque

7.0kgf.cm Min

Shaft play in rotational wobble

5°Max

Electrical characteristics

rating

DC 5V,A,B lead 5mA Max, C lead 10mA Max

resolution

15pules/360°

Insulation resistance

100MΩMin at DC50V

Dielectric

1 minute at AC 300V

Endurance characteristics

Rotational life

30000±200 cycles≤100gf.cm

Storage temperature range

-40℃≈85℃

Operating temperature range

-30℃≈80℃

Soldering characteristic

Dipping in soldering≤206℃±5°,within 3S

Solder by hand≤300℃±5°, within 3S
